PVBAT 16.58kWh Compact Wall-Mounted LiFePO4 Energy Storage Battery
The PVBAT 16.58kWh compact wall-mounted LiFePO4 energy storage battery is designed for modern home energy storage, solar power storage, home outage backup, and small off-grid systems. It combines large capacity with a compact body, making it suitable for homes, villas, apartments, small shops, and farms where installation space is limited.
Each unit provides 16.58kWh of energy storage capacity in a compact 671 × 461 × 285mm body. Compared with traditional energy storage batteries, it reduces installation space while maintaining high storage capacity. It can be wall-mounted directly for a cleaner, more modern, and lightweight residential energy storage layout.
The battery supports up to 20 units in parallel, reaching a maximum system capacity of approximately 331.6kWh. Users can flexibly expand storage capacity according to daily home power demand, solar system size, and backup runtime requirements. It can operate stably for daily solar storage, nighttime power supply, home backup power, and outdoor off-grid systems.
The system uses CATL LiFePO4 battery cells, offering high stability, fire and explosion resistance, and long service life. It supports long-term high-frequency charging and discharging, provides stable and reliable output, improves household energy utilization, and helps reduce long-term electricity costs.
- Compact wall-mounted installation with reduced space requirements.
- Supports multi-unit parallel expansion for flexible energy storage upgrades.
- Uses safe and reliable LiFePO4 battery cells.
- 10000-cycle design for stable long-term use.
- Supports solar energy storage, peak-valley power management, and outage backup.
- Supports off-grid power supply for remote areas and outdoor applications.
- Stable operation for long-term residential and commercial energy storage use.
- Modern appearance with a lighter and cleaner layout than traditional storage systems.
| Parameter Item | Elephant-48628 | BEAR-48G1 | FALCON-48G2 |
|---|---|---|---|
| Rated Energy | 32.15kWh | 20.48kWh | 16.5kWh |
| Rated Capacity | 628Ah | 400Ah | 324Ah |
| Rated Voltage | 51.2V | 51.2V | 51.2V |
| Charging Cut-off Voltage | 58.4V | 58.4V | 58.4V |
| Discharge Cut-off Voltage | 44.8V | 44.8V | 44.8V |
| Max. Continuous Discharge Current (Per Port) | 150Ah×2 | 150Ah×2 | 150Ah×2 |
| Battery Type | LiFePO4 (LFP) | LiFePO4 (LFP) | LiFePO4 (LFP) |
| Cycle Life | 8000 cycles @ 80% Depth of Discharge | 8000 cycles @ 80% Depth of Discharge | 10000 cycles @ 80% Depth of Discharge |
| Rated Voltage | 48V | 48V | 48V |
| Expansion Capability | Up to 20 batteries in parallel | Up to 20 batteries in parallel | Up to 20 batteries in parallel |
| Operating Temperature Range | Charge 0~55°C / Discharge -20~60°C | Charge 0~55°C / Discharge -20~60°C | Charge 0~55°C / Discharge -20~60°C |
| Communication Method | CAN/RS485 | CAN/RS485 | CAN/RS485 |
| Monitoring Method | Wi-Fi / Bluetooth | Wi-Fi / Bluetooth | Wi-Fi / Bluetooth |
| Battery Cell Configuration | 16S2P | 20S1P | 16S1P |
| Product Dimensions | 1000x900x340mm 39.37x35.43x13.39in |
1090x654x181mm 42.91x25.75x7.13in |
671x461x258mm 31.85x18.31x10.71in |
| Weight | 242kg / 533lbs | 150kg / 330lbs | 120kg / 265lbs |
| Installation Method | Wall-mounted / built-in casters | Wall-mounted / built-in casters | Wall-mounted / built-in casters |
| Waterproof Performance | IP54 | IP54 | IP54 |
Tip: The table can scroll horizontally on mobile devices.
Download User Manual
Download the PVBAT FALCON-48G2 User Manual PDF for installation guidance, operation instructions, safety information, and daily use reference.
